内蒙通辽旌派干式血浆速融机

内蒙通辽旌派干式血浆速融机

型    号: Jipad-6GL
报    价: 17
分享到:

内蒙通辽旌派干式血浆速融机 Jipad-6GL干式血液溶浆机利用隔水膜袋“隔水解冻",完全实现了血浆干式解冻的目的,解冻结束:“血浆外观干燥,透明、无水渍,污物,标签不会模糊、脱落"。

Jipad-6GL内蒙通辽旌派干式血浆速融机的详细资料:

内蒙通辽旌派干式血浆速融机产品说明:
Jipad品牌Jipad-6GL内蒙通辽旌派干式血浆速融机利用隔水膜袋“隔水解冻”,完全实现了血浆干式解冻的目的,解冻结束:“血浆外观干燥,透明、无水渍,污物,标签不会模糊、脱落”。特制热交换系统能够达到“快速解冻”的效果。专门设计的“摇匀系统”避免血浆内纤维蛋白凝结。“返回水设计”有利融化箱内水温恒定无热点。
Jipad-6GL干式血液溶浆机结构合理,紧凑,零部件经老化等特殊处理,性能稳定可靠,整机使用寿命长,不同型号的产品适合不同规模的医院输血科,血库使用,并经多家医院临床验证。
产品特点:
1. Jipad-6GL采用美国DS18B20和双金属片两级温控系统,超温自动报警并切断电源。解冻时间20分钟±2分钟。
2.专门设计的的“摇摆锤击”系统,避免血浆内纤维蛋白析出。“隔水膜袋”用医用绿色新型材料制成,无毒,无味,无毒副作用、使用寿命长。
3.水箱密封,长期不用换水,加入专用消毒剂(氯片)效果更好,节约资源减轻换水负担。仪器对环境不会有水渍、污物溢出,保护环境和操作人员。
4.如有血浆袋破裂因有隔水膜袋包裹,不会造成过量渗漏,污染水箱及环境.

技术参数:

1.电源电压:220V/50HZ
2.功率:1800W
3.可调温度:30℃---41℃<±1℃
4.解冻袋数:1-6袋(50-200毫升血浆)
5.解冻时间:10-20min±2min
6.容量:zui多12袋(200毫升血浆)
7.可调时间:1min--99.00min
8.仪器重量:29kg加水:45kg
9.外形尺寸:460X610X960(mm)
10.摇摆频率:50次/分钟
11.循环能力:40L

河北邯郸市旌派干式血液溶浆机装 机 方 法:

1、将压水棒放入隔水膜袋中
2、打开仪器上面小盖、加入干净的自来水,是纯净水。(仪器可长期不用换水。使用一段时间后,在仪器工作时,提起隔水膜袋观察水的清澈程度确定是否需要换水)
3、加水时请注意观察蜂鸣报警声停止,停止说明水位已加满请停止加水,过多加水,仪器左侧溢水口,会有水溢出。
4、加水过多时侧面会有水溢出,这样不会影响仪器使用,您可在侧面放水阀门放出少许即可。
5、等待40-50分钟显示屏实际温度显示37度,即可将血浆放入隔水膜袋中点击“开/关”按钮-------OK。
6、如需要改变设定温度、时间请参照操作手册。
一.目的
建立循环水浴箱解冻新鲜冰冻血浆、普通冰冻血浆及冷沉淀标准操作规程,规范冰冻血液成分解冻操作流程,确保血液质量安全。
二. 职责
本科室工作人员应用此操作规程,保证为临床提供安全的血浆。
三.原理
 冰冻血浆融化箱采用电气控制原理,新鲜冰冻血浆、普通冰冻血浆及冷沉淀等需要在 37  一 40℃稳定温度条件下,快速解冻防止蛋白成分析出 ,循环水溶箱可以维持稳定温度的水 浴条件,快速、批量觧冻,冰冻血液制品,确保觧冻速度和血液质量。
四.适用范围
适用于循环水浴箱解冻新鲜冰冻血浆、普通冰冻血浆及冷沉淀操作。
五、器材与试剂
1、器材:血库专用融浆机,血浆解冻袋
六、环境条件  温度:20-27℃,温度≤80% 七、操作程序:
1、连接进水管,排水管,接通电源;
2、打开电源开关,按“启动"键,提示“缺水"状态,拧开水龙头开始加水,直至进水完成,“预温"灯亮;
3、设定解冻湿度(一般设定为38℃)及解冻时间(根据解冻血浆数量确定,一般设定在16分钟以上);
4、待预温完成后,水箱水位上升到工作状态;
5、将血浆或冷沉淀从低温冰箱中取出,去掉包装盒,套上解冻袋,放入解冻槽中,盖好解冻箱盖;
6、解冻完成后,依次将血浆解冻袋取出,将血浆去掉解冻袋后放置室温下待用;
7、如果解冻后的血浆温度己经恢复到室温仍未发出,应该将血浆转移到4℃储血冰箱内待用。
八、注意事项
1、解冻箱应使用独立的三芯插座;
2、解冻箱上水时务必连好排水管,防止加水过量后溢水; 3、发现有破损血浆时需立即换水,并进行清洗
4、要避免血袋标签等物品落入水箱内,以免堵塞水管,致使水循环系统瘫痪;
5、解冻箱长期不用时,应将解冻箱内的水全部排尽。
九、保养与维护
1、解冻箱应每周做清洗保养一次,清洗内外表面;
2、温度校正:每年由计量部门对解冻箱进行一次温度检测,如发现实测温度与显示温度相差0.5℃以上,应对解冻箱进行校正
Product Description:
The Jipad brand Jipad-6L dry blood plasmapheresis machine uses the water separating membrane bag to separate the water and thaw. The purpose of plasma dry thawing is compley realized. The end of thawing is: "the appearance of the plasma is dry, transparent, waterless, dirty, and the label will not be fuzzy and falling off". The special heat exchange system can achieve the effect of "fast thawing". The specially designed "shake up system" avoids fibrin condensation in the plasma. The "return water design" is favorable for the constant water temperature in the melting box without hot spot.
The Jipad-6L dry blood dissolving machine has a reasonable and compact structure. The components are treated by aging and other special treatments. The performance is stable and reliable, and the whole machine has long service life. Different types of products are suitable for different scale hospitals transfusion department, blood bank is used, and is verified by many hospitals.
Product features:
The 1. Jipad-6L dry blood plasma dissolve machine adopts the two level temperature control system of American DS18B20 and bimetallic chip, which can alarm automatically and cut off the power. The thawing time was 20 minutes and 2 minutes.
2. specially designed "swing hammer" system to avoid fibrin precipitation in the plasma. "Water diaphragm bag" is made of new medical green materials, which is non-toxic, tasess, non-toxic side effects and long service life.
3. water tank is sealed for a long time without changing water. The effect of adding special disinfectant (chlorine tablet) is better, saving resources and reducing the burden of water exchange. The instrument does not have water stains, spillage of dirt, protection of the environment and the operator.
4. if the rupture of a plasma bag is wrapped in a membrane bag, it will not cause excessive leakage and pollute the water tank and the environment.
Technical parameters:
1. power supply voltage: 220V/50HZ
2. power: 1800W
3. adjustable temperature: 30 C ---41 C < + 1 c
4. the number of thawing bags: 1-6 bags (50-200 ml plasma)
5. thawing time: 10-20min + 2min
6. capacity: a maximum of 12 bags (200 ml of plasma)
7. adjustable time: 1min--99.00min
8. instrument weight: 29kg adding water: 45kg
9. shape size: 460X610X960 (mm)
10. swing frequency: 50 times / minute
11. cycle ability: 40L
Installation method:
1. Put the water rod in the water - proof bag
2. Open the top of the instrument and add clean tap water. It is best to clean water. (the instrument can not change water for a long time. After working for a period of time, in the work of the instrument, the clarity of water in the water diaphragm bag is raised to determine whether the water is needed for water exchange.
3, when you add water, please observe the stop of the beep alarm, stop indicating that the water level has been filled, stop adding water, add too much water, and the overflow on the left side of the instrument will overflow the water.
4, when the water is overloaded, there will be water overflow, which will not affect the use of the instrument, you can release a little on the side of the water valve.
5, waiting for 40-50 minutes to display the actual temperature of the display 37 degrees, you can put the plasma into the water septum bag and click "open / close" button -------OK.
6, if you need to change the setting temperature and time, please refer to the operation manual.
I. purpose
Establish standard operation procedures for circulating frozen water tank, thawing fresh frozen plasma, ordinary frozen plasma and cold precipitation, and standardize the operation process of frozen blood components, so as to ensure the quality and safety of blood.
Two. Responsibilities
The staff in this department use this procedure to ensure the safety of plasma in the clinic.
Three. Principle
Frozen plasma melting box adopts the principle of electrical control, fresh frozen plasma, ordinary frozen plasma need to be in a stable temperature 37 to 40 DEG C, rapid thawing to prevent protein precipitation, circulating water soluble box can maintain stable temperature of water bath, fast and batch frozen frozen blood products, explanation, to ensure that the explanation of freezing the speed and quality of blood.
Four. Scope of application
It is suitable for the defrosting of fresh frozen plasma, common frozen plasma and cold precipitation.
Five, equipment and reagents
1. Equipment: a special thawing machine for blood bank, a plasma thawing bag
Six, the environmental conditions of temperature: 20-27 degrees, the temperature is less than or equal to 80%, seven operating procedures:
1, connect the inlet pipe, drain pipe, connect the power supply;
2, open the power switch, press "start" key, prompt "water shortage" state, turn off the faucet start adding water, until the water is completed, "pre temperature" light;
3, set the thawing humidity (generally set to 38) and thawing time (according to the number of thawing plasma is determined, generally set at more than 16 minutes);
4. When the temperature is finished, the water level of the water tank rises to the working state.
5. Remove the plasma or cold precipitation from the cryogenic refrigerator, remove the packing box, set the thawing bag, put it in the thawing tank, and cover the thawing box cover.
6. After the defrosting is completed, the plasma thawing bag is taken out in turn, and the plasma is removed after the defrosting bag is placed at room temperature.
7, if the plasma temperature after thawing has not been released to room temperature, the plasma should be transferred to 4 centigrade to be used in the blood storage refrigerator.
Eight. Precautions
1. An independent three core socket should be used in the thawing box.
2, when the thawing box is on the water, be sure to connect the drain pipe to prevent overflowing water. 3, when the damaged plasma is found, water should be changed immediay and cleaned.
4, to avoid the blood bag label and other articles fall into the water tank, so as to avoid blocking the water pipe, causing the water circulation system to be paralyzed.
5. When the thawing box is not used for a long time, all the water in the thawing box should be exhausted.
Nine, maintenance and maintenance
1, the thawing box should be cleaned and maintained once a week, and the inside and outside surface should be cleaned.
2, temperature correction: once a year, the temperature measurement of the thawing box is carried out by the Metrology Department. If we find the difference between the measured temperature and the display temperature is more than 0.5 degrees, we should adjust the thawing box.

1血液溶浆机就称为:干式血液融浆机 干式血液溶浆机 ,隔水式血液溶浆机,水浴血液溶浆机 ,气浴血液溶浆机,多功能血液溶浆机,全自动血液溶浆机,台式血液溶浆机,立式血液溶浆机。
2.血液融浆机就称为:干式血液融浆机 ,隔水式血液融浆机,水浴血液融浆机 ,气浴血液融浆机,多功能血液融浆机,全自动血液融浆机,台式血液融浆机,立式血液融浆机
3.化浆机就称为:干式化浆机 ,隔水式化浆机,水浴化浆机 ,气浴化浆机,多功能化浆机,全自动化浆机,台式化浆机,立式化浆机
4.血浆溶浆仪就称为:干式血浆溶浆仪 ,隔水式血浆溶浆仪,水浴血浆溶浆仪 ,气浴血浆溶浆仪,多功能血浆溶浆仪,全自动血浆溶浆仪,台式血浆溶浆仪,立式血浆溶浆仪
